Description
The portable ALUMILITE FOLDING CURB RAMP has all the features of the Solid Curb Ramp but folds in half for ease of carrying, and features an integrated handle and closing strap. The 29" width model allows the ramp to fit in vans with narrow doors. This style of ramp is sometimes referred to as a suitcase ramp.
Features
- Decide on Location. Where will you use the ramp? How much space is available? If using a portable ramp will storage be an issue?
- Measure the Rise. Measure from the ground to the bottom of the door, porch, or van where the ramp will start. On doors remember to include the height of the threshold.
- Check the slope. AlumiRamp and the ADA recommend a slope of 1:12 (1 inch of vertical rise to 12 inches of ramp length.) or 4.8° for Ramp Systems. Portable ramps are often used at much steeper slopes but too steep a ramp can be dangerous and difficult to climb.
- Determine Layout. The AlumiRamp Dealer Book includes a Site Evaluation Form to help with laying out a Ramp System. Or call us direct and we will design a system that meets your needs, and send you a drawing and quote.
AlumiRamp
AlumiRamp designs, manufactures, and delivers a full line of aluminum access ramps to promote active lifestyles for people with disabilities.We pioneered the modular system in 1986 and now offer four lines to meet your exact needs, from the smaller threshold to the highest porch. As well as portable aluminum ramp options. AlumiRamp specializes in all types of code issues from ADA and ANSI to IBC and OSHA. We are happy to advise you on any code questions you may have and discuss which system will meet your needs. ?
-
Specs
- MODEL; ACR3FN OPEN SIZE; 29" W x 3' L CLOSED SIZE; 15" W X 3' L WEIGHT; 18 lbs. WEIGHT CAPACITY; 600 lbs.
- MODEL; ACR4FN OPEN SIZE; 29" W x 4' L CLOSED SIZE; 15" W X 4' L WEIGHT; 24 lbs. WEIGHT CAPACITY; 600 lbs.
- MODEL; ACR5FN OPEN SIZE; 29" W x 5' L CLOSED SIZE; 15" W X 5' L WEIGHT; 30 lbs. WEIGHT CAPACITY; 600 lbs.
- MODEL; ACR6FN OPEN SIZE; 29" W x 6' L CLOSED SIZE; 15" W X 6' L WEIGHT; 37 lbs. WEIGHT CAPACITY; 600 lbs.
- MODEL; ACR3FW OPEN SIZE; 36" W x 3' L CLOSED SIZE; 18" W X 3' L WEIGHT; 20 lbs. WEIGHT CAPACITY; 600 lbs.
- MODEL; ACR4FW OPEN SIZE; 36" W x 4' L CLOSED SIZE; 18" W X 4' L WEIGHT; 26 lbs. WEIGHT CAPACITY; 600 lbs.
- MODEL; ACR5FW OPEN SIZE; 36" W x 5' L CLOSED SIZE; 18" W X 5' L WEIGHT; 32 lbs. WEIGHT CAPACITY; 600 lbs.
- MODEL; ACR6FW OPEN SIZE; 36" W x 6' L CLOSED SIZE; 18" W X 6' L WEIGHT; 41 lbs. WEIGHT CAPACITY; 600 lbs.
-
Size Chart / measuring guide
-
Warranty Information
LIMITED WARRANTY
AlumiRamp, Inc. warrants its products against defects in material and workmanship for 10 (ten) years from the date of purchase. This covers all aluminum and fasteners. Straps, bungees, and non skid tape are expected to show wear even under normal use and are not covered under this warranty. Defective units will be repaired or replaced, at our option, and returned to the original purchaser freight paid, provided the ramp is sent freight prepaid to us along with proof of purchase. This warranty is void in case of abuse, improper use, incorrect assembly, overloading, or neglected maintenance of the product.
In no event shall AlumiRamp, Inc., be liable for special, incidental or consequential damages or injuries, or for any loss, damage, or injury resulting directly or indirectly from any occurrence which this product is represented to avoid.
This warranty is in lieu of all other guarantees either expressed or implied and is valid only in the United States and Canada. In some States, limitation on the length of the warranty period is prohibited. This warranty recognizes any and all rights you may have under appropriate State law.
If warranty work is required, contact the dealer or place of original purchase. AlumiRamp, Inc. will then be contacted and a return authorization form will be filled out and an authorization number assigned by the factory. No product is to be returned to the factory without proper authorization.
Upon receipt, AlumiRamp, Inc. will assess the problem and determine the proper course of action. If warranty work is required, the product will be repaired or replaced and returned as outlined above.
AlumiRamp, Inc. reserves the right to refuse any warranty work on product that shows obvious abuse or use other than what the product was originally designed for.
Please check the instruction manual for maintenance and safety information concerning the proper care and use of the ramps.
