M1 Seat Frame

Ref #	Description	Part #	Replaces	Price	Quantity
Ref # 1.1	Description BHCS K6S 5x10 fzb-C	Part #: 601353-C	Replaces: 601353-99-0	Price Reg. Price: $14.00
Ref # 5.1	Description BOLT K6S 6x12 fzb-O	Part #: 601422-99-O	Replaces: 601422-99-0	Price Reg. Price: $14.00
Ref # 6.1	Description BOLT MC6S 6x16 fzb-L	Part #: 600743-L	Replaces: 600743-99-0	Price Reg. Price: $14.00
Ref # 9.1	Description BOLT MC6S 8x 12 fzb SHCS-A	Part #: 600705	Replaces: 600705-99-0	Price Reg. Price: $14.00
Ref # 12.1	Description BOLT MF6S 8x25 fzb,-A	Part #: 600744	Replaces: 600744-99-0	Price Reg. Price: $14.00
Ref # 8.1	Description END CAP FOR UT THIN RAIL (QTY 1)-A	Part #: 315427	Replaces: 1824301	Price Reg. Price: $14.00
Ref # 18.1	Description BRACKET, SEAT EXTENSION LEFT, CENTER MNT LEGR, M1-A	Part #: 331932	Replaces: 1834600	Price Reg. Price: $23.92
Ref # 19.1	Description BRACKET, SEAT EXTENSION RIGHT,CENTER MNT LEGR, M1-A	Part #: 331889	Replaces: 1834601	Price Reg. Price: $23.92
Ref # 20.1	Description UNITRACK EXTENSION, M1 FOR AMP SUPPORT, EACH-A	Part #: 333041	Replaces: 1834443	Price Reg. Price: $32.24
Ref # 7.1	Description UT RAIL, SEAT FRAME, M1 14" - 22" SEAT WIDTH, EA.-A	Part #: 331296	Replaces: 1834468	Price Reg. Price: $32.24
Ref # 16.1	Description BRACKET, BACKREST, LEFT SEAT FRAME MOUNT, M1-A	Part #: 332092	Replaces: 1834628	Price Reg. Price: $40.56
Ref # 17.1	Description BRACKET, BACKREST, RIGHT SEAT FRAME MOUNT, M1-A	Part #: 332091	Replaces: 1834467	Price Reg. Price: $40.56
Ref # 2.2	Description SEAT PLATE, FRONT & REAR 16", NO HDW, M1-A	Part #: 1834602	Replaces: 1834602	Price Reg. Price: $76.96
Ref # 2.3	Description SEAT PLATE, FRONT & REAR 18"W, NO HDW, M1-A	Part #: 1834604	Replaces: 1834604	Price Reg. Price: $81.12
Ref # 2.4	Description SEAT PLATE, FRONT & REAR 20"W, NO HDW, M1-A	Part #: 1834605	Replaces: 1834605	Price Reg. Price: $86.32
Ref # 2.5	Description SEAT PLATE, FRONT & REAR 22"W, NO HDW, M1-A	Part #: 1834606	Replaces: 1834606	Price Reg. Price: $90.48
Ref # 14.1	Description SEAT FRAME, COMPLETE FOR 14"W SEAT/BACK SIZE, M1-A	Part #: 1834473	Replaces: 1834473	Price Reg. Price: $474.24
Ref # 14.2	Description SEAT FRAME, COMPLETE FOR 16"W SEAT/BACK SIZE, M1-A	Part #: 1834472	Replaces: 1834472	Price Reg. Price: $488.80
Ref # 14.3	Description SEAT FRAME, COMPLETE FOR 18"W SEAT/BACK SIZE, M1-A	Part #: 1834471	Replaces: 1834471	Price Reg. Price: $504.40
Ref # 14.4	Description SEAT FRAME, COMPLETE FOR 20"W SEAT/BACK SIZE, M1-A	Part #: 1834470	Replaces: 1834470	Price Reg. Price: $517.92
Ref # 14.5	Description SEAT FRAME, COMPLETE FOR 22"W SEAT/BACK SIZE, M1-A	Part #: 1834469	Replaces: 1834469	Price Reg. Price: $537.68

Quick & Easy Checkout

M1 Seat Frame

BHCS K6S 5x10 fzb-C

BOLT K6S 6x12 fzb-O

BOLT MC6S 6x16 fzb-L

BOLT MC6S 8x 12 fzb SHCS-A

BOLT MF6S 8x25 fzb,-A

END CAP FOR UT THIN RAIL (QTY 1)-A

BRACKET, SEAT EXTENSION LEFT, CENTER MNT LEGR, M1-A

BRACKET, SEAT EXTENSION RIGHT,CENTER MNT LEGR, M1-A

UNITRACK EXTENSION, M1 FOR AMP SUPPORT, EACH-A

UT RAIL, SEAT FRAME, M1 14" - 22" SEAT WIDTH, EA.-A

BRACKET, BACKREST, LEFT SEAT FRAME MOUNT, M1-A

BRACKET, BACKREST, RIGHT SEAT FRAME MOUNT, M1-A

SEAT PLATE, FRONT & REAR 16", NO HDW, M1-A

SEAT PLATE, FRONT & REAR 18"W, NO HDW, M1-A

SEAT PLATE, FRONT & REAR 20"W, NO HDW, M1-A

SEAT PLATE, FRONT & REAR 22"W, NO HDW, M1-A

SEAT FRAME, COMPLETE FOR 14"W SEAT/BACK SIZE, M1-A

SEAT FRAME, COMPLETE FOR 16"W SEAT/BACK SIZE, M1-A

SEAT FRAME, COMPLETE FOR 18"W SEAT/BACK SIZE, M1-A

SEAT FRAME, COMPLETE FOR 20"W SEAT/BACK SIZE, M1-A

SEAT FRAME, COMPLETE FOR 22"W SEAT/BACK SIZE, M1-A
