Rear Caster Wheel and Fork Assembly, 6" Wheels

Ref #	Description	Part #	Replaces	Price	Quantity
Ref # D1	Description NUT, LOCK, M12X1.75, 12 HIGH, 19 WIDE. ISO 898-2, CL 8, BZ, PVTP (SEE DRAWING)-A	Part #: NUTNYLK1013	Replaces:	Price Reg. Price: Starting At: $3.06
Ref # G1	Description SCREW, PAN HEAD, TYPE H, M3X0.5 X 6, ISO 7045, CL 4.8, BZ-A	Part #: HDW1803914	Replaces:	Price Reg. Price: Starting At: $3.06
Ref # I1	Description SCREW, PAN HEAD, TYPE H, M4X0.7 X 8, FT, ISO 7045, CL 4.8, BZ-F	Part #: SCRPPH1036	Replaces:	Price Reg. Price: Starting At: $3.06
Ref # E1	Description WASHER, FLAT, 13 ID X 24 OD X 2.5 THK, ISO 7089-12-200 HV, BLK-A	Part #: WASMETR1032	Replaces:	Price Reg. Price: Starting At: $3.06
Ref # J1	Description REFLECTOR,AMBER,CASTER SPHERE,C-1202-027-C	Part #: DWR1202C027	Replaces:	Price Reg. Price: Starting At: $3.12
Ref # F1	Description PLASTIC CAP, CASTER ARM-A	Part #: DGN1808787	Replaces:	Price Reg. Price: Starting At: $4.59
Ref # H1	Description COVER,CASTER SPHERE,BLACK,6" WHEEL,THIN,LOW PROFILE,D-1202-044	Part #: DWR1202D044	Replaces:	Price Reg. Price: Starting At: $15.66
Ref # C1	Description CASTER BEARING KIT-A	Part #: MEC122534	Replaces:	Price Reg. Price: Starting At: $90.51
Ref # B1	Description WHEEL,ASSY,LOW IMPACT,BLACK RIM/BLACK TIRE,6" X 2",W/BEARINGS & SPACER,E-1202-039	Part #: WHLASMB7110039	Replaces:	Price Reg. Price: Starting At: $92.28
Ref # A1b	Description CASTER ASSEMBLY, 6", BLACK RIM / BLACK TIRE, LEFT (DWG 151499	Part #: MEC151499-B	Replaces:	Price Reg. Price: Starting At: $128.00
Ref # A1a	Description CASTER ASSEMBLY, 6", BLACK RIM / BLACK TIRE, RIGHT (DWG 151501	Part #: MEC151501-B	Replaces:	Price Reg. Price: Starting At: $128.00

gift guide

Quick & Easy Checkout

Rear Caster Wheel and Fork Assembly, 6" Wheels

NUT, LOCK, M12X1.75, 12 HIGH, 19 WIDE. ISO 898-2, CL 8, BZ, PVTP (SEE DRAWING)-A

SCREW, PAN HEAD, TYPE H, M3X0.5 X 6, ISO 7045, CL 4.8, BZ-A

SCREW, PAN HEAD, TYPE H, M4X0.7 X 8, FT, ISO 7045, CL 4.8, BZ-F

WASHER, FLAT, 13 ID X 24 OD X 2.5 THK, ISO 7089-12-200 HV, BLK-A

REFLECTOR,AMBER,CASTER SPHERE,C-1202-027-C

PLASTIC CAP, CASTER ARM-A

COVER,CASTER SPHERE,BLACK,6" WHEEL,THIN,LOW PROFILE,D-1202-044

CASTER BEARING KIT-A

WHEEL,ASSY,LOW IMPACT,BLACK RIM/BLACK TIRE,6" X 2",W/BEARINGS & SPACER,E-1202-039

CASTER ASSEMBLY, 6", BLACK RIM / BLACK TIRE, LEFT (DWG 151499

CASTER ASSEMBLY, 6", BLACK RIM / BLACK TIRE, RIGHT (DWG 151501
