Description

Catalyst 5 V x Catalyst 5 V x Front View

Unleash the transformative power of color

Express your authentic style by crafting a truly distinctive and personalized look using the new Color Accent option. Color Accents provide a subtle highlight of color using an ultra-durable powder coat finish on a select group of parts.* To explore our curated palette of complimentary colors available in the new Color Accent package visit the Color section. This upgrade is available at no additional charge.

*The Color Accent option on Catalyst 5Vx includes the following parts: Forks and Axle Plate.

Better Adjustment

Center of gravity adjustment and ride performance go hand in hand. The redesigned axle plate and rear frame give you 2” (5.08 cm) of center of gravity adjustment in 1/2” (1.27 cm) increments and 5” (12.7 cm) of rear seat height adjustment over 7 positions. Find your fit, ease your propulsion and optimize the ride you’ve come to expect with Catalyst.

Adjustable Camber

The Adjustable Camber comes at no charge, giving you up to 4° of camber in 1” increments. A simple adjustment and convenient option provides you with the parts up front so you have everything you need when adjusting or fine tuning camber later.

Style

Personalizing your Catalyst 5Vx begins with you. Pick your greatest shade then highlight your look with our anodizing package, options and accessories. With thousands of color combinations to choose from, be bold. Be you.

300 lbs Standard Weight Capacity

Weighing in at a mere 13.9 lbs transport weight*, Catalyst 5Vx is the lightest and strongest folding wheelchair on the market with a 300 lbs standard weight capacity! A heavy duty option is also available.

Swing-In Anti-Tip

Without sacrificing the compact frame design, the easy to activate Swing-In Anti-Tips swing in under the frame so they are there when you need them and gone when you don't. Available in pairs, Left or Right mounting options.

Fender Side Guards

Choose between carbon fiber and foam padded aluminum side guards with fender to protect your clothing from the road while adding a sleek look to your chair.

Transit Wheels

Integrated into the rear frame for a minimalistic look, Transit Wheels allow you to remove the rear wheels for easier access through narrow spaces. The transit wheels are adjustable across a range of rear wheel and rear seat height combinations.

Front Frame Styles

Catalyst 5Vx offers the option of a swing away front end featuring our patented footrests or 70° or 80° fixed frames. The swing away hangers come in 4 bends (60°, 70°, 80° & 90°) are light and easy to use and so strong we offer a lifetime warranty.

Mag

Exclusive to Ki, the magnesium Maxx Mag wheel creates a sleek, modernized look while providing greater stiffness and lower weight than classic nylon composite mag wheels. Maxx Mag wheels are available in 20”, 22” and 24”.

Power Assist Compatible

Twist by Klaxon redefines what is possible in power assist. Fully compatible with atalyst 5Vx, Twist is designed to integrate effortlessly. Hardware comes preinstalled, and user drive settings are pre-programmed. That means that it is ready to roll, right out of the box. Twist stands apart as the only power assist solution to combine front and rear drive capability in a single, intuitive system. Discover how Twist is transforming mobility by delivering more freedom and flexibility, and fewer compromises.

Specifications
Dimensions
Transport Weight:	13.9 lbs	Frame Material:	700 Series Aluminum
Standard Weight:	24 lbs	Top Frame Tubing size:	1"
Seat Width:	14" - 22"	Bottom Frame Tubing size:	1 1/8"
Seat Depth:	14" - 20"	Weight Capacity:	300 lbs
Front Seat Height:	13.5" - 21"	Weight Capacity HD:	350 lbs
Rear Seat Height:	11.5" - 21"
Camber:	0°, 2°, 4°, 6°, 8°
Axle Positions Available:	7
Center of Gravity Adj. Increments:	0.5"
Center of Gravity Adj. Range:	2"

Colors

Gloss Matte

Color Anodizing

Size Chart / measuring guide

A-
Seat Depth

Measure from the most posterior point of the body to the inside of the knee, minus at least two inches. Some prefer more leg overhang to make room for their hand when lifting their leg.

B-
Back Height

Measured from the seat base to the top of the wheelchair back. Depends on how much upper back support is needed, and also affects freedom for the upper body to rotate.

c-
Rear Seat to Floor

Measurement from the ground to the rear seat edge. Relative to the front seat-to-floor dimension, this determines the rearward slope ("dump" or "squeeze") of the wheelchair seat.

D-
Hanger Angle

Determines how far the toes extend away from the body, measured from the horizontal. A tighter angle allows the wheelchair to turn around in less space. Depends in part on ability of the knee to bend towards the perpendicular

E-
Seat Width

Determined by the widest point of the body from knee to hip, plus an inch to ensure room to move. Consider bulk of clothing, particularly a heavy winter coat, if relevant.

F-
Wheel Camber

Angle of the wheel relative to the vertical. More camber improves stability and agility, but also limits ability to pass through narrow spaces. A typical daily wheelchair uses three degrees of camber.

G-
Front Seat to Floor

Measure the leg from the back of the knee to the sole of the foot. Then subtract the thickness of the cushion when it is compressed. Next, add a minimum of two inches for footrest clearance. Do not add the footrest clearance if the wheelchair will be foot-propelled.

H-
Footrest Width

Measure from the inside of each leg rest tubing the distance or desired distance between leg rests.

H-
Footrest Width

Measure from the inside of each leg rest tubing the distance or desired distance between leg rests.

I-
Center of Gravity

Measure from the front of the seat back post to the center of the rear axle.

J-
Seat to Footrest Length

Measure from the edge of the seat upholstery to the top rear of the footrest.

K-
Backrest Angle

Measure the angle of the back post to the floor. Ninety degrees will be perpendicular to the floor, to approximate the angle from the back post to the seat, subtract two degrees from measurement for every .5" of dump
