Optimized Charging for your Permobil PowerchairThe new Permobil VoltPro charger delivers a unique charging profile that modulates voltage and current to completely and efficiently charge Permobil batteries. The optimized charging not only reduces charging time, it also helps extend battery life.Permobil’s battery charger is an off-board charger designed to efficiently charge the batteries used in Permobil’s power wheelchairs. The advanced fan-free design means that charging is quiet. The charging process is automatically adapted to the current condition of the battery, which optimizes the service life of the batteries and ensures that the charging time is as short as possible. When the battery is fully charged the charger will enter maintenance mode. The battery cannot be overcharged.Operation
When you connect the charger to the wall socket, it will do two
tests: a test of the seven LEDS in a sequence, and an internal test that
is finished when the orange on/off LED comes on. The battery
charger indicator tells you the current charging status when you
charge the batteries. When the batteries are fully charged, the
charger switches to maintenance mode.
1. Connect the contact to the wheelchair’s charging socket.
2. Connect the contact to the wall socket.
3. Charge the wheelchair’s batteries until the charging indicator’s
green LED for 100% comes on.
4. Disconnect the contact from the wall socket.
5. Disconnect the contact from the wheelchair’s charging socketAvailable for:
- M3 Corpus
- M5 Corpus
- F3 Corpus
- F5 Corpus
- F5 Corpus VS
- M1
- M400 Corpus HD
Technical specifications
Charging current (low ripple) 8 A at 100-165 V mains voltage
10 A at 165-240 V mains voltage
Compatible batteries 24 V, 30–100 Ah, Type Gel, AGM
Efficiency in percent >= 93%
Short circuit and incorrect polarization safe Yes
Spark-free connection Yes
Overheat protection Yes
Mains voltage 100–240V ~ 50/60 Hz, ±10%
Charging algorithm IUIa/DIN 41773 Standard
Nominal charging voltage 24 V DC
Enclosure class IP21 or IP54. See label on battery charger for enclosure class type.
Insulation class II (double insulation) -
