Specifications



Permobil M1 power wheelchair
Maximum user weight	300 lbs.
Maximum speed	5 mph
Driving range	16 miles*
Base width	24"
Base length	35.5"
Minimum turning radius	20.5"
Ground clearance	3"
Optional seat elevator	12"
Recommended battery type	Group 34
Weight Including Batteries	319 lbs**
Drive electronics	R-Net 90A, VR2 PM 90 (Advanced) or PM 70 (Advanced and Basic)
Seat to floor height	16",17",18"
Tilt options	0° - 50°
Recline options	85° – 110° (manual)
Legrest angle	80 – 140° (power) [ >19" seat depth]
	90 – 150° (power) [ ≤19" seat depth]
	80 – 135° (manual)
Backrest Height	18" – 29" (by 1" increments)
Seat depth	14" – 22" (by 1" increments)
Seat Width	14" – 22" (by 2" increments)
Armrest Options	2"x10", 2"x14", 4"x10", 4"x13"	NOTE* †Specifications may vary based upon configuration. Please refer to your owners manual for warnings and instructions for the safe operation of your wheelchair in a variety of driving conditions. ††The maximum user weight for a seat depth of 14” cannot exceed 165 lbs. * Actual driving range will vary based on driving and battery conditions. **Includes weight of base, curved backrest and battery.
